K-SB-10試驗數據采集系統

K-SB-10 Testing bench data gathering system

軟件介紹

用傳統手工方法和測量手段測量氣體壓力、溫度、流量等參數, 不僅精度低, 速度慢,可靠性差, 而且測量時耗費人力; 采用以計算機為基礎的《試驗數據采集系統》可快速、準確測量氣體壓力、溫度、流量等參數, 測量精度高, 測量數據可靠,并可自動完成數據處理、存儲等任務。《試驗數據采集系統》可大大節省人力,降低成本; 減輕勞動強度, 改善勞動環境; 測量速度的提高, 可減少測量時間, 提高工作效率; 采用《試驗數據采集系統》, 可大大提高測量數據精度及可靠性, 為新產品開發設計、科研提供強有力的保證. 本產品可用于新產品開發試驗測量, 產品常規試驗測量及科研試驗測量等多種場合。

采用《試驗數據采集系統》, 可擺脫傳統手工測量落后局面, 進入自動化、智能化測量新時代, 提高企業形象和在市場中的競爭力。

Software introduction

It is not only low precision, slow speed, poor reliability, but also labor-consuming to measure gas pressure, temperature, flow and other parameters by traditional manual methods and measurement means. The computer-based "Test Data Acquisition System" can quickly and accurately measure gas pressure, temperature, flow and other parameters, with high measurement accuracy and reliable measurement data, and can automatically complete data processing, storage and other tasks. "Test data acquisition system" can greatly save manpower and reduce costs; Reduce labor intensity and improve working environment; The improvement of the measuring speed can reduce the measuring time and improve the working efficiency; The adoption of "Test Data Acquisition System" can greatly improve the accuracy and reliability of measurement data, and provide a strong guarantee for the development, design and scientific research of new products. This product can be used in many occasions such as new product development test measurement, product routine test measurement and scientific research test measurement.

The adoption of that t data acquisition system can get rid of the backward situation of the traditional manual measurement, enter a new era of automatic and intelligent measurement, and improve the image of the enterprise and the competitiveness in the market.

K-SB-10試驗數據采集系統

K-SB-10 Data Acquisition System

軟件主要功能

根據用戶測量需要, 可快速、靈活配置采集通道傳感器及測量參數名稱；
■ 支持采集參數自動采集功能, 實現采集參數自動采集、自動保存；
■ 采集系統的實時顯示功能, 可實時地顯示被測參數；
■ 支持非采集(人工測量)參數鍵盤輸入功能, 實現非采集參數輸入, 做到測量參數方法的多樣性；
■ 支持傳感器零漂補償功能, 提高測量精度；
■ 單個工況多次采集參數功能，適合于用畢托管測量流量的場合使用；
■ 系統測量精度高, 重復性好；
■ 采用圖形界面，操作簡單，使用方便；無需專業人員，均可學會使用；
■ 全面支持Windows2000及WindowsXP；
■ 符合GB/T 1236-2000新標準。

《試驗數據采集系統》可以與《通風機試驗數據處理系統》聯合使用，試驗采集的數據可直接傳送到《通風機試驗數據處理系統》中,實現數據采集、處理一體化。

The main function of software

According to the user's measurement needs, it can quickly and flexibly configure the names of acquisition channel sensors and measurement parameters;

■ Support the function of automatic acquisition of acquisition parameters to realize automatic acquisition and automatic saving of acquisition parameters;

■ Real-time display function of the acquisition system, which can display the measured parameters in real time;

■ Support the keyboard input function of non-acquisition (manual measurement) parameters, realize the input of non-acquisition parameters, and achieve the diversity of measurement parameter methods;

■ Support the zero drift compensation function of the sensor to improve the measurement accuracy;

■ Multiple parameter acquisition function for single working condition, suitable for the occasion of measuring flow with Pitot tube;

■ The system has high measurement accuracy and good repeatability;

■ Graphical interface, simple operation, easy to use; no need for professionals, can learn to use;

■ Full support for Windows 2000 and Windows XP;

■ Meet the new standard of GB/T 1236-2000.

The test data acquisition system can be used together with the ventilator test data processing system, and the data collected in the test can be directly transmitted to the ventilator test data processing system to realize the integration of data acquisition and processing.

K-SB-10通風機試驗數據處理系統

K-SB-10 Fanner test bench data processing system

軟 件 介 紹

■ 采用圖形界面和32位編程技術, 操作簡單, 使用方便, 操作者無師自通；
■ 采用圖文排版技術, 使文字、曲線與圖形在本系統內一次完成及輸出；
■ 采用模擬顯示技術, 可直接在屏幕上顯示所制作的報告, 所見所得；
■ 采用網絡打印技術, 支持在網絡打印機上輸出及彩色打印；
■ 全面支持Windows98,Windows2000及Win XP。

軟 件 功 能
■ 支持四種試驗類型
　風室試驗：A型出氣試驗、A型進氣試驗、B型出氣試驗和C型進氣試驗；
　風管試驗：B型出氣試驗、C型進氣試驗、D型進出氣試驗(B型)和D型進出氣試驗(C型)；
■ 流量測量方法(錐型集流器、弧型集流器、畢托管和多噴嘴流量計)、
■ 功率測量方法(平衡電機法、扭矩儀法、電測法);
■ 根據屏幕顯示的試驗裝置圖輸入試驗裝置數據和測試數據;
■ 自動處理試驗數據, 計算結果自動生成表格;
■ 自動繪制試驗風機的有因次性能曲線和無因次性能曲線;
■ 自動生成試驗報告并可對試驗報告進行編輯、修改和打印輸出。
■ 符合GB/T1236-2000通風機試驗新標準。

software introduction
■ Adopt graphical interface and 32-bit programming technology, easy to operate, easy to use, the operator is self-taught;

■ Adopt graphic-text typesetting technology, so that text, curves and graphics can be completed and output at one time in the system;

■ Using analog display technology, the report produced can be displayed directly on the screen, what you see and what you get;

■ Network printing technology is adopted to support output and color printing on network printers;

■ Full support for Windows 98, Windows 2000 and Win XP.

software function
■ Four types of trials are supported

　Wind chamber test: Type A air outlet test, Type A air inlet test, Type B air outlet test and Type C air inlet test;

　Air duct test: Type B air outlet test, Type C air inlet test, Type D air inlet and outlet test (Type B) and Type D air inlet and outlet test (Type C);

■ Flow measurement methods (cone type header, arc type header, pitot tube and multi-nozzle flowmeter),

■ Power measurement method (balance motor method, torque meter method, electrical measurement method);

■ Input the test device data and test data according to the test device diagram displayed on the screen;

■ Automatic processing of test data and automatic tabulation of calculation results;

■ Automatically draw the dimensional and dimensionless performance curves of the test fan;

■ Test reports are automatically generated and can be edited, modified and printed out.

■ Meet the new standard of GB/T1236-2000 fan test.
